Is it possible to
combine a high performance CD player
with an FM and DAB tuner as well as
state-of-the art D Class
amplification all in one supremely
elegant aluminium sheath that will
match any contemporary room décor?
Indeed it is. The CDI10 requires
only a pair of capable speakers to
deliver musical pleasure of
exceptional quality in any room.
The CDI10 is the first model in a
new Primare range of compact systems,
featuring effortless integration in
your home or office environment, an
unsurpassed ease of use,
groundbreaking technologies and the
usual beautiful aesthetics.
|
|
FM RADIO |
|
|
Tuning Range: |
87.5 - 108 Mhz |
|
RDS: |
RDS decoding |
|
Number of Presets: |
40 |
|
Usable Sensitivty: |
FM mono: 10dBuv
FM-stereo: 20dBuv |
|
|
|
|
DAB |
|
|
Tuning Range: |
Band lll: 174-240
Mhz
Band L: 1452-1492 Mhz |
|
Usable Sensitivity: |
Band lll: 29dBuV
Band L: 30dBuV |
|
Number of Presets: |
10 |
|
|
|
|
CD Player |
|
| Mechanism: |
DVS DSL-710 |
|
D/A Converter: |
PCM 1738, 24-bit 192
kHz |
| |
|
|
Amplifier |
|
|
Output Power: |
2 x 75 W into 8 Ohm,
class D |
|
Frequency Response: |
20 Hz - 20 kHz +/-
0.3 dB |
|
THD+N 20Hz-20kHz: |
10 W below 0.1 % |
|
Power Supply: |
Dual Switch Mode |
|
Power Consumption: |
Standby: 16 W,
Operate: 210 W |
|
Inputs: |
3 RCA (L&R)
1 3.5 mm Jack (front) Line In |
|
Outputs: |
1 3.5 mm Jack
(front) headphone
1 RCA (L&R) Pre Output
1 RCA (L&R) Tape Output
1 TOS link |
|
Other Inputs: |
1 75R SPDIF (RCA)
1 IR input
1 RS232 Input
50 R Antenna F-connector, combined
DAB/FM |
| |
|
| |
|
|
Gewicht: |
8kg |
|
Breedte: |
480 mm |
|
Hoogte: |
106 mm |
|
Diepte: |
385 mm |
