> Symphonika - 2.5 way Bass Reflex floorstander Multipaneel System EVO



Symphonika - Flagship model
A journey into Audel quality. We started with the evolution of our patents. We have implemented the IRS system in its EVO version. We have studied a solution to increase the size of the sound stage without losing the focus of the sound stage. Finally we tried to isolate our speaker by studying an unparalleled technology, applied to the Symphonika base.

Esoteric Components - new Beryllium Tweeter and Neodymium Woofer
Non-resonant beryllium dome tweeter with separate two-piece aluminum front for integrated mechanical decoupling. Double balanced compression chamber for better dynamics 6.5-inch woofer with ventilated aerodynamic die-cast aluminum chassis for optimal strength and low compression. Cone with Egyptian papyrus fibres. Powerful low distortion neodymium motor system.

SVS patent - Stop Vibration System
the new base, designed specifically for Symphonika, is designed to ensure perfect isolation of the speaker. Three independent layers interspersed with O-rings guarantee the absorption of outgoing and incoming vibrations. 4 adjustable tips are further isolated with the use of anti-vibration isolators made of Fenix specifically designed for symphonika and included in the basic package.

IRS EVO patent - The evolution of the species
Implement our already performing one. Internal Ribs System required an in-depth analysis of the internal tensions to which our structure is subjected during sound emission. We extended the frequency emission range, increased the internal pressure and adapted the structure by inserting two Fenix sheets that divide the structure into three. This choice reduces the potential deformation of the structure caused by internal tensions. A choice that also gives a very elegant appearance, making the Audel design unique and increasingly identifiable

Specifications
- System: 2.0 integrated bass reflex
- Cabinet: multipanel system EVO – Structure laminated birchwood and fenix panel
- Tweeter: 29 mm soft dome Berillio
- Woofer: 61/2 inch Magnete al neodimio
- Frequency response: 47 hz – 25.000 hz
- Crossover point: 2.400 hz
- Sensitivity: 92 db
- Nominal impedance: 4 ohm
- Power handling: 30w–200w
- Finish: birch cabinet – beeswax surfaces
- Dimensions: 1120 x 410 x 220 mm (hxwxd)
- Shipping weight: 80 kg pair.



> Finish



FRONT SITE

Walnut

FRONT SITE
Burl Walnut
